Library Of Mmana Antenna Files
MMANA Quick Start Optimization part1 Optimization part2 Optimization part3 Optimization part4 A short antenna optimization tutorial using MMANA-GAL Al Couper NH7O These pages will present a short guide to antenna optimization using MMANA-GAL. This program has a very complete optimization engine, which is unique for free software. Berkeley Electronic Press Selected Works. Computer Antenna Modeling Simplified. Added a possibility to save a picture of the antenna and currents in a.jpg file. Into the mmana.ini file. Directories are added to the antennas' library. 47 rows All antenna files provided here are free for private use. MMANA-GAL allows users to save the results of Calculations in a special file ( antenna name.mab). By default the.mab file is stored in the same directory as the antenna file. Note that if this is a new antenna project it is advisable to first save the file in a suitable directory in the MMANA-GAL Library e.g C.MMANA-GAL-GAL ANT my antennas/.
Below are ZIP files containing large collections of pattern files for RFI Base station antennas. Each pattern file type is compatible with various coverage simulation software packages available today.
Click on the links below to download the corresponding ZIP file of your choice
MMANA-GAL - Download as PDF File (.pdf), Text File (.txt) or read online. Merged antenna files Undo/Redo Auto check wires Speed of calculation. The Dual Band 7/10MHz Dipole with LC Trap from the MMANA-GAL Library. Notice that the radiation resistance (impedance) is about 90 ohms. This antenna can be matched to 50 ohms by using a series inductor.
- For TIA/EIA-804-B standard files download our ADF library, compatible with many popular propagation simulation software packages available today.
Mmana Gal Antenna Files
- For Pathloss v4 try our VAF file library, and the ASD file library for Pathloss v5
- For MSI Planet propagation software download the PLN file library
- For EDX download the PAT file library
- For an NSMA WG16.99.050 download the DAT file library
- The ANA file library has been provided for proprietary software
The W8IO/ WB0DGF Antenna Site
YAGiosoftware
(10 June 2015)
YAGio - Yagi Design by W8IO
YAGio 1.01 is themost current released version. YAGio runs underWindows 2000, XP, Vista, Win 7 and likely Win 8. YAGio is similar to LPCAD, it uses keyboard commands instead of amouse menu. YAGio allows you to create DL6WU long Yagi antennas on anyfrequency, typically on VHF and UHF ham frequencies. You specify thefrequency, desired gain, type of element to boom mounting, DE diameterand parasitic element diameter, and YAGio does the rest. Youcan save these designs in 5 different formats - YIO (used by YAGio),NEC (used by 4NEC2), YAG (YO), MMA (MMANA-GAL) and YC6 (used by YagiCAD). You can alsoprint the results to your Windows default printer. Please emailme at rgcox2 (at) gmail.com if you find bugs or to suggestimprovements. YAGio.exe version 1.01 was created on 6-10-2015 at 12:39 pm. The exe file size is 221K. You may downloadYAGio101.ZIP here.
I am currently working on YAGio 1.02. I will also add file export support for4 bay NEC models.
Ilike to useMmana Nec
4NEC2to evaluate my Yagi models. It is a very nice,full featured version of NEC2. You can find the latestversion of4NEC2 here:
You can also find a fasterNEC2 'engine' for 4NEC2 here: http://users.otenet.gr/~jmsp/ TheNEC2/MP'engine' will speed up computation tremendously in dual and quad corePC's. A modelthat took 60 seconds to run in 4NEC2's existing computation engineshould complete under 25 seconds using the NEC2/MP engine in a dualcore CPU and under 12 seconds in a quad core CPU.
Here are a couple screen shots from YAGio 1.0 running in Win 7:Mmana Download
The bonez astronaut rar files 2017. NEC Software for Yagi Design
| Software / Version / Author | Type of Yagi Design | Input/Open/Import File Formats | Save/Export File Formats | Price |
| 4NEC2 version 5.8.14 Arie Voors | includes sample Yagi and other antenna files, full pattern and gain analysis | .nec .ez (EZNEC) .ant (AO) | .nec .txt | Free |
| EZNEC version 5 Roy Lewallen W7EL | includes sample Yagi and other antenna files, full pattern and gain analysis | .ez (EZNEC) .en | .ez | EZNEC v. 5 ($89) EZNEC+ v.5 ($139) EZNEC Pro/2 v.5 ($500) |
| AutoEZ Demo 2.0.10 Dan Maguire AC6LA | - | .weq (AutoEZ) .ez (EZNEC) .nec .ant (AO) .inp .maa (MMANA-GAL) | .weq (AutoEZ) .ez (EZNEC) | Demo - Free full version - $79 |
| YagiCAD 6.2.0 Paul McMahon VK3DIP | includes sample Yagifiles, full pattern and gain analysis | .yc6 (YagiCAD) .yag (YagiCAD) | .yc6 (YagiCAD) .nec .nec (4NEC2) .txt | Free |
| YW- Yagi for Windows 2.0 Dean Straw N6BV | unable to open filesunless moved to new directory | .yw (Yagi forWindows) .yag (YO) | .yw (Yagi forWindows) | includedin ARRL Antenna Handbook |
| Yagi Calculator 2.6.10 John Drew VK5DJ | DL6WU long boom Yagi creation | no file import | .yag (YO) .maa (MMANA-GAL) | Free |
| YAGio 1.01 Roger Cox W8IO | DL6WU long boom Yagi creation | .yio (YAGio) | .nec (4NEC2, EZNEC) .yc6 (YagiCAD) .yag (YO) .maa (MMANA-GAL) | Free |
| CocoaNEC 2.0 Kok Chen W7AY | - | .nec | ? | Free (Mac OS-X version of NEC) |
| MMANA-GAL | - | ? | ? | ? |
| NEC2GO | - | .nec | .nec | $39.95 |
Note: K6STI's AO and YOsoftware no longer available. His older versions will not work inWindows 7 and 8 unless DOSBox is also used.
Library Of Mmana Antenna Files Free
Commentsare welcome!
contactRoger: email to
rgcox2(at) gmail.com
Mmana Gal Basic
Roger Cox W8IO - SpringLake, MI
